SAE J517 100R3 HYDRAULIC HOSE

SAE J517 100R3 HYDRAULIC HOSE

SAE 100R3 LOW PRESSURE HOSE

Applications： Suitable to convey medium like petroleum basedhydraulic oil, lubrication oil, water, and air

Tube：Black oil-resistant synthetic rubber
Reinforcement：Two braids oftextile
Cover：Black oil, weather, and abrasion resistantsynthetic rubber
Temperature Range：-40°C~+100°C(40°F~+212°F)

Fiber braid hydraulic hose

SEND ENQUIRY:WHATSAPP +86 15903958655

SAE J517 100R3 Hydraulic Hose Reference standard :

SIZE(Dash)SIZE(in.)  I.D.(mm)O.D.(mm)Max.W.P.Min.B.P.Min.B.R.W.T
MinMax
Min
Max(MPa)(MPa)(mm)
kg/m
1bft
-33/164.65.5
11.9
13.610.54275
0.15
0.14
-41/46.17.0
13.4
15.18.734.875
0.16
0.16
-55/167.48.5
16.7
18.38.433.6100
0 .25
0.21
-63/89.310.1
18.3
19.87.831.2100
0.31
0.26
-81/212.313.5
22.8
24.6728125
0.40
0.38
-105/815.516.7
26.2
27.86.124.4140
0.51
0.42
-123/418.519.8
30.7
32.55.220.8150
0.61
0.58
-16125.126.2
36.8
39.23.915.6205
0.91
0.74
-201 1/431.432.9
42.8
45.22.610.4250
1.10
0.77

SAE J517 100R3 Hydraulic Hose Standards, Manufacturing, Use, Whatever other insights you may have, please feel free to share them with us, thank you!

FAQ about hydraulic hose applications

Hydraulic hose has a wide range of applications in mining, military, engineering machinery, metallurgy, petroleum, chemical industry, aviation and navigation.
According to the different structure of the skeleton layer, the hydraulic hose can be categorized as braided hose and winding hose, etc.
according to the different materials of the hydraulic hose skeleton, the hydraulic hose can be categorized as steel wire hydraulic hose and cotton thread hydraulic hose, etc..
